3.2.4 Cable Specifications
Cable Slack (Excess Length)
Cable slack is needed for each cable and varies from cable to cable. Contact the Brainlab site
coordinator for more details, unless otherwise stated in this document.
ExacTrac
Cables installed by Brainlab
The following table provides an overview of all ExacTrac cables that need to be pulled by
Brainlab, their start and end point as well as their size and correct orientation. All other building
installation cables for system interlocks are not listed here (for more information, see
page 81).
Reference Nr.
Cable Name
Conduit
Reference
START
START
(Component, Plug,
Cable)
END
END
(Component, Plug,
Cable)
Note Cable
Direction
Plug @ START
Plug @ END
Max. Cable
Length [m]
Cable Diameter
[m]
Largest Plug
Dimensions
[mm]
Shipped with
Pre-Insall-Kit
Shipped with
Main Shipment
Module
Cable Type
12A
XR High Volt-
age Cable
M 2.0a HVT/(+) 2.2a
Tube/(+)
Anode
11/15/1
8
17 180x70 x XR
Power Tube
150kV
12B
XR High Volt-
age Cable
M 2.0a HVT/(-) 2.2a
Tube/(-)
Cathode
11/15/1
8
17 180x70 x XR
Power Tube
150 kV
12C
XR High Volt-
age Cable
M 2.0b HVT/(+) 2.2b
Tube/(+)
Anode
11/15/1
8
17 180x70 x XR
Power Tube
150 kV
12D
XR High Volt-
age Cable
M 2.0b HVT/(-) 2.2b
Tube/(-)
Cathode
11/15/1
8
17 180x70 x XR
Power Tube
150 kV
13A
XR Stator Ca-
ble
M 2.0a Sub-D./X6 2.2a
Tube/
Stator
x
Attached to
tube
11/15/1
8
12 x XR
Power Stator
230 V
13B
XR Stator Ca-
ble
M 2.0b Sub-D./X6 2.2b
Tube/
Stator
x
Attached to
tube
11/15/1
8
12 x XR
Power Stator
230V
25
ET EXGI
CDOS Cable
1.0 LC x 4-pin
9-pin
DSUB
6 x Gating Data, Gating
27
Cat 5E Patch
Cable
U 1.0
WS/LAN
Conn.
4.0
Network
Plug
RJ45 RJ45 4 5 14x11 x Patch
38
PEQ, 16 mm
2
M 2.0 2.2a
2)
9 N/A x XR PEQ
39
PEQ, 16 mm
2
M 2.0 2.2b
2)
9 N/A x XR PEQ
ExacTrac Cables installed by the Contractor
The following table provides an overview of all ExacT
rac cables that need to be pulled by the
contractor
, their start and end point as well as their size and correct orientation. All other building
installation cables for system interlocks are not listed here (for more information, see page 81).
Reference Nr.
Cable Name
Conduit
Reference
START
START
(Component, Plug,
Cable)
END
END
(Component, Plug,
Cable)
Note Cable
Direction
Plug @ START
Plug @ END
Max. Cable
Length [m]
Cable Diameter
[m]
Largest Plug
Dimensions
[mm]
Shipped with
Pre-Insall-Kit
Shipped with
Main Shipment
Module
Cable Type
1
ET Video Ca-
ble
H
1.0
Video Fr.
Grabber
1.1
Video
Adapter
C.
x
7-pin
thin
7-pin
thick
30 8 35 x IR Video
2 ET KVM Cable B1 1.0 Dual KVM 1.3
KVM (in-
room)
30 5 14x11 x IR Patch
3
ET Serial Ex-
tension
B1 1.0 COM 3 1.3 Cable 16 x
FE-
MALE
MALE 30 9 31x15 x IR
Touch Exten-
sion
4
ET Infrared
USB Adapter
H 1.0 USB B 1.1
Spectra
Camera
x
Adapt
er
MALE 30 7 x IR Data/Power
5A
ET Flatpanel
Data Cable
C 1.0
FG with
lower ID
2.3a
FP1
(right)/
Data
30 8 50x34 x XR FP Data
5B
ET Flatpanel
Data Cable
C 1.0
FG with
higher ID
2.3b
FP2 (left)/
Data
30 8 50x34 x XR FP Data
Cabling
24 Site Planning Manual Rev. 1.0
ExacTrac Ver. 6.x
