3.5 Heat Dissipation
Calculation
The calculations used to determine the heat dissipation are based on the following:
• 1000 BTU/h = 293 W
•
1 W = 3.412 BTU/h
X-Ray Dual Generator and Tubes
In stand-by mode, the heat dissipation for the X-ray dual generator and tubes is approximately
250 W (853 BTU/h).
For air condition layout, use 400 W (1365 BTU/h): 100 W for each generator (2 in total) plus 100
W for each tube (2 in total) = 400 W.
Computer Cabinet and All System Components
Measured: 406 W (1386 BTU/h)
For air condition layout, use: 500 W (1706 BTU/h)
SITE SPECIFICATIONS
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 33
