6.2 Control Room Workspace
General Information
Figure 34
Component Description
Equipment
Keyboard, mouse, 19” flat-screen monitor, Ex-
acTrac
Console (for system power, X-ray expo-
sure, and remote motion enable).
Location
It is highly recommended for the ExacTrac
workspace and the linac workspace to be as
close as possible to the control room area. This
allows smoother integration of workflows for
the operators.
Required Space Approximately 700 mm as pictured above.
Power Supply/
Data Connections
Located in the control room distribution box.
CONTROL ROOM
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 71
