13.3 Electrical Infrastructure
Checklist
Yes No n/a 3 Electrical Infrastructure Comments Scheduled
3.1 Provide a power distribution box.
Your power distribution box
must provide the power and
if applicable the required sig-
nals to the ExacTrac
equip-
ment. An on/off circuit should
allow you to safely power on
or down the equipment.
3.2
Provide the schemas of the power
distribution box.
By providing the schemas of
the power distribution box to
be built, Brainlab can guaran-
tee if the requirements for
ExacTrac
are met.
3.3
Provide flexible power cable with
400 VAC, three phase + neutral N
+ ground PE, 50/60 Hz; maximum
wire cross section of 35 mm²
(4A
WG) to the bottom of the gen-
erator with a minimum of 2 m
slack. TN star network is required.
3.4
Provide flexible power cable with
230 VAC, one phase + neutral N +
ground PE, 50/60 Hz; maximum
wire cross section: 2.5 mm² to the
bottom of the computer cabinet
with a minimum of 2 m slack.
3.5
For safety reasons:
It is required to install a power
switch close to the computer cabi-
net and X-ray generator
.
Alternative: Locker system in your
electric distribution panel.
The power cut of
f must be
protected by a unique key.
Standard keys are not ac-
cepted by Brainlab.
3.6
Connection of the power lines to
the computer cabinet and X-ray
generator must be performed by
your electrician supported by a
Brainlab technician.
3.7
PEQ reference bar: T
o be instal-
led by customer near generator or
computer cabinet, connect all
Brainlab grounding cables.
3.8
PEQ 16 mm² cable between PEQ
reference bar and computer cabi-
net.
3.9
PEQ 16 mm² cable between PEQ
reference bar and X-ray genera-
tor
.
3.10
Install a network plug RJ 45 close
to the computer cabinet (maxi-
mum 2 m from the cabinet).
