3.2.2 Cable Conduits
Sample Treatment Room Set-Up
The following image shows an overview of cable conduits (diagram not meant to scale):
3.2
In-Room
Distribution Box
Control-Room Workplace
External
Bluetooth Module
Stand & Gantry
0.0
Primary
Beam
1.3
Control Room
Distribution Box
1.5
Isocenter
2.4
ExacTrac Console
Control-Room
Workspace
1.6
Tube 1
Tube 2
2.2a
2.2b
1.0
Computer Cabinet
Hospital
Network
4.0
X-Ray
Dual Generator
2.0a 2.0b
2.3b
2.3a
1.2
1.2
1.1
2.5a
2.5b
Warning Light
Warning Light
Flatpanel
Flatpanel
IR Camera
L
LL
A Ø75mm
D1 Ø75mm
G2 Ø50mm
J
T Ø25mm
M Ø130mm
O Ø25mm
R Ø50mm
I Ø25mm
(optional)
C Ø75mm
H2
Ø25mm
P Ø25mm
B1 Ø75mm
G1 Ø50mm
(optional)
S Ø75mm
= Ø25mm
= Ø50mm
= >Ø75mm
_
H1
Ø50mm
D2 Ø75mm
B2 Ø75mm
E Ø50mm
K Ø25mm
M Ø130mm
U Ø25mm
Grounding
Spot
Figure 3
SITE SPECIFICATIONS
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 19
