12.3 Cable Classifications
General Information
The following table lists detailed information about cable types that may be required by your
regulatory bodies:
Art. No. Name Voltage
Applied
Voltage
Rating
Jacket
T
ype
UL List-
ed
UL Recog-
nized AWM
styles
ExacT
rac
Application
Classifica-
tion
49541
X-ray control
panel cable
24 VDC 250 V PUR CMX #
Communica-
tion
Class II
49302-03
ET4 power ca-
ble kit (mains 3
x 2.5q mm)
230 VAC 600 V PVC # 21098/ 2587
Fused power
supply
, low
voltage
Class I
49302-03
ET4 power ca-
ble kit (PE 2.5
qmm)
n/a
600 V PVC # 1015
Protective
earth
#
49302-03
ET4 power ca-
ble kit (PE 16
qmm)
n/a 600 V PVC # 1015
Protective
earth
#
49073 ET KVM Cable < 15 V 125 V PVC CMR #
Communica-
tion
Class II
49025A
ET serial ex-
tension
< 15 V 30 V PVC # 2502
Communica-
tion
Class II
49554-30
ET flat panel
data cable
< 15 V 30 V PVC # 20276/ 2990
Communica-
tion
Class II
49562A
ET flat panel
DC cable
12 VDC 300 V PVC # 2464/1061
Power supply
extra low volt-
age
Class II
49341-10
ET touch VGA
cable
< 15 V 30 V PVC # 20276/ 2990 Video Class II
49342
ET touch data
cable
< 15 V 300 V PVC # 2095
Communica-
tion
Class II
49301-09
ET touch pow-
er extension
12 VDC 300 V PVC # 2464
Power supply,
extra low volt-
age
Class II
49202-6 ET video cable < 15 V 300 V PVC # 2464 Video Class II
49367
ET IR USB
adapter
< 15 V 150 V PVC CL2 #
Power limited
cicuit cable
Class II
49525-11A
X-ray high volt-
age cable UL
1
1m
70 kV
75 kV PVC # (E187096)
High voltage
X-ray
#
49526-26A
X-ray stator
cable 11m
230 V
AC 600 V PVC # 2839
Fused motor
drive, low
voltage
Class I
49545
ET warning
light cable
12 VDC 300 V PVC CL2P #
Power limited
circuit cable
Class II
46133-01
ET console ca-
ble
24 VDC 250 V PUR CMX #
Communica-
tion
Class II
49776-10
RTM cross
over cable
< 15 V 250 V PUR CMX #
Communica-
tion
Class II
