4.1.4 Customized Cable Outlet
General Information
It may be necessary (e.g., for updates) to widen the cable outlet on the 12” Floor Boxes.
The following image shows the allowed area for customizing the cable outlet in the rear wall of the
floor boxes.
480
185
480
185
12” Floor Boxes (Standard)
