Steps
6
Place first one half and then the second
half of the cardboard protection cover on
top of the wooden cover. Slide the
edges under the metal rim ①.
7
Use duct tape to connect the two halves
of the protection cover.
8
Pour quick drying concrete into the gap
around the floor box up to the finished
floor.
finished floor
330mm
> 10mm
filled up with
concrete
At least 10 mm of the rim of the aluminum cover must rest on stable
(concrete) floor.
The ET floor box must be fixed to the pit with anchors (not supplied
by Brainlab) and be set in concrete.
Use mineral material only. Do not use chemical filling.
FLOOR BOXES
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 41
