12.5 Types of Networks for Electricity Supply
General Information
THREE-PHASE STAR
FOUR-WIRE
EARTHED NEUTRAL
A
THREE-PHASE STAR
THREE-WIRE
B
THREE-PHASE STAR
THREE-WIRE
EARTHED NEUTRAL POINT
C
THREE-PHASE STAR
FOUR-WIRE
NON-EARTHED NEUTRAL
D
TWO-PHASE STAR
THREE-WIRE
EARTHED NEUTRAL
E
THREE-PHASE DELTA
THREE-WIRE
F
THREE-PHASE DELTA
FOUR-WIRE
EARTHED MID POINT OF PHASE
G
THREE-PHASE OPEN DELTA
FOUR-WIRE
EARTHED MID POINT OF PHASE
THREE-PHASE OPEN DELTA
FOUR-WIRE
EARTHED JUNCTION OF PHASES
SINGLE-PHASE
THREE-WIRE
EARTHED MID POINT
SINGLE-PHASE
TWO-WIRE
EARTHED END OF PHASE
SINGLE-PHASE
TWO-WIRE
NON-EARTHED NEUTRAL
SINGLE-WIRE
EARTHED RETURN (SWER)
V AV
d.c.
THREE-WIRE
H
LK
N P
J
M
Figure 47
Types of Networks for Electricity Supply
