Brainlab ExacTrac - Wall-Mounted Touch Screen Monitor (Standard)

5.4 Wall-Mounted Touch Screen Monitor (Standard)
Dimensions
292
483
recommended installation height: 1500
ground floor
Figure 31
How to Attach a Wall Mounted T
ouch Screen Monitor to a Drywall
Steps
1.
Use anchors and screws (4x) appropriate
for your wall (e.g., drywall anchors and
screws for drywalls).
19"/48.5 cm
CEILING AND WALL MOUNTS
Site Planning Manual Rev. 1.0 ExacTrac Ver. 6.x 65
