13.2 Ceiling Brackets
Checklist
Yes No n/a 2 Ceiling Brackets Comments Scheduled
2.1
Mark position anchors on the ceil-
ing.
2.2
Remove obstacles/providing alter-
native anchoring platforms.
2.3 Provide anchors.
The contractor must provide
the appropriate anchors to
hold the weight of the ceiling
brackets.
2.4
Assemble and fix ceiling brackets:
IR camera mount; 200 kg
2.5
Assemble and fix ceiling brackets:
Flat panel mounts (x 2); 200 kg.
2.6
Fix steel rope angle plates (x 4); L
configuration
.
2.7
Assemble and fix ceiling brackets.
2.8
Assemble and fix the wall monitor
mount; 10 kg and ceiling mounted
monitor arm; 400 kg.
2.9
Fix the in-room distribution box; 6
kg
2.10
Fix the control-room distribution
box; 6 kg.
2.11
Fix the Brainlab warning lights; 1
kg.
2.12
You must provide a written “State-
ment of Compliance” about fixa-
tion of all ceiling mounts and floor
boxes in accordance to respective
local regulations and Brainlab pre-
installation parameters.
The contractor statement of
compliance is mandatory to
complete the acceptance
protocols.
2.13
Adapt the false ceiling to the new
penetrations (from ceiling brack-
ets).
The final position of the
Brainlab suspending equip-
ment cannot be precise until
the end of the installation.
The false ceiling must be
adapted after Brainlab has
completed installation.
2.14
Storage of Brainlab’s cables until
final installation.
Brainlab’s data cables are
delivered together with the
ceiling brackets. They must
be kept in a safe place until
their installation or until they
are pulled.
