The following image shows the recommended position of the ceiling mounted monitor:
alternative
Position
1250mm
1800mm
R max=
1910mm
R min=
890mm
R= 1170mm
Figure 30
Ceiling-Mounted Touch Screen Monitor (Optional)
62 Site Planning Manual Rev
. 1.0
ExacTrac Ver. 6.x
