Chapter 2: Introduction to the 2000X aed Actuator
Glossary of Terms
Reject Limits: User-definable limits at which the violating cycle is identified as having pro-
duced a bad part.
Required: State used with limits indicating that a reset will be required when the limit is
exceeded. The reset is accomplished by using the reset key on the front of the Power Supply.
Reset Required: State used with limits indicating that a reset will be required when the limit is
exceeded. The reset is accomplished by using the reset key on the front of the Power Supply.
Run Screen: The screen showing weld status, alarms, weld count, and process information.
Available using a front-panel button on the Power Supply.
Save Preset: Stores a programmed set of weld parameters as a Preset.
Scrub Time: In Ground Detect mode, the amount of time after detection of a ground condition
before the termination of ultrasonics, and end of the cycle.
Seek: The activation of ultrasonics at a low-level (5%) amplitude, for the purpose of finding the
resonant frequency of the Stack.
Serial Port: A RS232 port provided to you for external data communications.
Step @ Energy: User-definable point at which AmpA is changed to AmpB.
Step @ Ext Sig: Allows you to shift either force or amplitude based upon an external signal.
Step @ Power: User-definable point at which AmpA is changed to AmpB.
Step @ Time: User-definable point at which AmpA is changed to AmpB.
Suspect Limits: User-definable limits at which the resultant weld in a welding cycle is identi-
fied as potentially bad (suspect).
Test Scale: The magnification of the power bar on the front panel of the Power Supply, useful
for lower-power applications that want a more accurate (but smaller) scale.
Time Mode: Terminates the ultrasonics at a user-specified time.
Timeout: A time at which the ultrasonic energy terminates if the main control parameter has not
been reached.
Trigger Beeper: An audible signal sounded when the trigger force has been met, and the trigger
switch is made.
Trig Delay: Trigger Delay. A user-programmable time delay between engagement of the trigger
switch and start of ultrasonics and ramping of force to the weld force.
User-defined Limits: for process resultants, where - is the user-defined lower limit, and + is the
user defined upper limit:
-/+ S/R Energy: The energy reached during the weld.
-/+ S/R Freq: The peak frequency reached during a weld.
-/+ S/R Power: The peak power as a percentage of the maximum reached during the weld.
-/+ S/R Abs D: The absolute distance reached during the weld from the Upper Limit
Switch.
-/+ S/R Col D: The collapse distance reached from trigger to end of weld.
