4-10 100-214-276 Rev. 3
Chapter 4: Installation and Setup
Installation Requirements
4.4.2 Environmental Specifications
4.4.3 Electrical Input Power Ratings
Plug the Power Supply into a single-phase, grounded, 3-wire, 50 or 60 Hz power source. Table 4.4 lists the
current and fuse ratings for the various models.
The ground screw on the rear of the actuator must be connected to earth ground with #8 gauge wire.
Table 4.4 Input Power requirements
* requires a special 20 amp 120V receptacle
Table 4.3 Environmental Specifications
Environmental Concern Acceptable Range
Humidity 30% to 95%, non-condensing
Ambient Operating Temperature +5°C to +50°C (41°F to 122°F)
Storage / Shipping Temperature
-25°C to +55°C (-13°F to +131°F);
Up to +70°C (+158°F) for 24 hours
For 15 kHz models 3300 W 200V - 240V 21 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
For 20 kHz models
1250 W 200V - 240V 7 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
1250 W 100V - 120V 14 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
2500 W 200V - 240V 14 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
3300 W 200V - 240V 21 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
4000 W 220V - 240V 25 Amp Max. @ 220V / 25 Amp fuse NEMA L6-20P Plug
For 30 kHz models
750 W 100V - 120V 10 Amp Max. @ 100V / 20 Amp fuse NEMA 5-20P Plug
750 W 200V - 240V 5 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
1500 W 100V - 120V* 26 Amp Max. @ 100V / 20 Amp fuse NEMA 5-20P Plug
1500 W 200V - 240V 10 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
For 40 kHz models
400 W 200V - 240V 3 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
400 W 100V - 120V 5 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
800 W 200V - 240V 5 Amp Max. @ 200V / 20 Amp fuse NEMA L6-20P Plug
800 W 100V - 120V 10 Amp Max. @ 100V / 20 Amp fuse NEMA 5-15P Plug
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
