100-214-276 Rev. 3 4-33
2000X aed Actuator Chapter 4: Installation and Setup
Instruction Manual Assemble the Acoustic Stack
4.8 Assemble the Acoustic Stack
The following procedure must be performed by a setup person. If necessary, secure the larg-
est portion of a square or rectangular horn in a soft jawed (brass or aluminum) vise. NEVER
attempt to assemble or remove a horn by holding the converter housing or the booster clamp
ring in a vise.
Do not use silicone grease with Mylar washers. Use only 1 (one) Mylar washer of the correct
inside and outside diameters at each interface.
Table 4.9 Tools
Step Procedure
1
Order and obtain the Rack Mount kit for your Power Supply. The brackets in the Kit are
designed for standard 19-inch rack mounting options.
2
From the front corners of the Power Supply, remove the Front Corner bezels by removing
the two Phillips screws. Save the screws.
3
Noting that one side of each bracket is countersunk to accept the provided flathead
screws, assemble the Rack Mount Handles as shown in Figure 4.21
’Detail of Rack
Mount Handle Kit Assembly’ on page 4 - 32. (This shows only the Right bracket and han-
dle; the left side is a mirror-image.) Tighten the screws securely and so they are flush.
4
Re-using the screws you removed in Step 2, install the assembled Handle in place of the
Front Corner pieces.
5
Save the removed hardware corner pieces.
6
When you are ready to install the unit, use the hardware from your Rack Mounting system
to locate the Power Supply.
Tool EDP Number
15, 20, and 30 kHz Torque Wrench Kit 101-063-787
40 kHz Torque Wrench 101-063-618
15 kHz spanner Wrench 201-118-034
20 kHz Spanner Wrench 101-118-039
30 kHz Spanner Wrench 201-118-033
40 kHz Spanner Wrench 201-118-024
Silicone Grease 101-053-002
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
