100-214-276 Rev. 3 3-1
2000X aed Actuator Chapter 3: Delivery and Handling
Instruction Manual Shipping and Handling
Chapter 3: Delivery and Handling
3.1 Shipping and Handling - - - - - - - - - - - - - - - - - - - - - - 3-1
3.1.1 Environmental Specifications - - - - - - - - - - - - - - - - - - 3-1
3.2 Receiving - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-2
3.3 Unpacking- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-3
3.3.1 Actuator Assemblies - - - - - - - - - - - - - - - - - - - - - - 3-3
3.4 Returning Equipment - - - - - - - - - - - - - - - - - - - - - - - 3-3
3.1 Shipping and Handling
3.1.1 Environmental Specifications
The 2000X aed Actuator is a system of cast and electro-pneumatic components that move the
ultrasonic tooling in the ultrasonic welding system and control aspects of the weld process.
Many of its components can be harmed if the unit is dropped, shipped under improper condi-
tions, or otherwise mishandled. The following environmental guidelines should be respected in
the shipping of the 2000X aed Actuator unit.
Table 3.1 Environmental Specifications
Environmental Condition Acceptable Range
Humidity 30% to 90% non-condensing
Storage / Shipping Temperature
-25°C/-13°F to +55°C/+131°F (+70°C/+158°F
for 24 hours)
Shock / Vibration (transit)
60 g shock / 0.5 g and (3-100 Hz) vibration per
ASTM 3332-88 and 3580-90
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
