100-214-276 Rev. 3 7-5
2000X aed Actuator Chapter 7: Maintenance
Instruction Manual Parts Lists
7.3 Parts Lists
The following tables list the available Accessories and Parts for the 2000X aed Actuator (tables
7.2 and 7.3, respectively) and for the 2000X aed 15kHz Actuator (tables 7.4 and 7.5, respec-
tively):
Table 7.2 Accessories List for 2000X aed Actuator
Description EDP Number
2000X aed Actuator with 1.5-inch diameter cylinder 101-134-252
2000X aed Actuator with 2.0-inch diameter cylinder 101-134-253
2000X aed Actuator with 2.5-inch diameter cylinder 101-134-256
2000X aed Actuator with 3.0-inch diameter cylinder 101-134-259
aod Actuator with 1.5-inch diameter cylinder 101-134-276
aod Actuator with 2.0-inch diameter cylinder 101-134-277
aod Actuator with 2.5-inch diameter cylinder 101-134-278
aod Actuator with 3.0-inch diameter cylinder 101-134-280
aodl Actuator with 2.5-inch diameter cylinder 101-134-279
aodl Actuator with 3.0-inch diameter cylinder 101-134-281
Kit Base Guard (for large horns) 101-063-550
Remote Pneumatics Box (rp) ao 2 1/2", 3.0" 101-134-1350
Remote Pneumatics Box (rplf) 1 1/2", 2" ao 101-134-1351
Inch Leveling Plate 101-063-358
Metric Ball Bolt (adapts 2000X base to leveling plates) 100-298-085
Metric Leveling Plate 101-063-444
CJ20 Acorn (in actuator) 101-135-059
CA30 Acorn 101-135-114
30kHz Booster Adapter Ring (for use with CA30) 100-087-283
4TJ Acorn (in actuator) 101-135-041
40 kHz Adapter Sleeve Assy (same as 900) 100-246-612
Stand-Base 4" OD,, 3.5" ID, col, support 100-246-1314
Stand-Hub, 4" OD, col, support 100-246-1344
Base, ergo - 4” metric, black 100-246-1313
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
