100-214-276 Rev. 3 6-1
2000X aed Actuator Chapter 6: Operation
Instruction Manual Actuator Controls
Chapter 6: Operation
6.1 Actuator Controls - - - - - - - - - - - - - - - - - - - - - - - - - 6-1
6.2 Initial Actuator Settings - - - - - - - - - - - - - - - - - - - - - - 6-2
6.2.1 Regulated Air Pressure and Air Pressure Gauge - - - - - - - - 6-2
6.2.2 Factory Air Source - - - - - - - - - - - - - - - - - - - - - - - 6-3
6.2.3 Downspeed Control - - - - - - - - - - - - - - - - - - - - - - 6-3
6.2.4 Actuator Alignment and Height (Horn travel) - - - - - - - - - - 6-4
6.2.5 Mechanical Stop - - - - - - - - - - - - - - - - - - - - - - - - 6-4
6.2.6 Emergency Stop - - - - - - - - - - - - - - - - - - - - - - - - 6-5
6.3 Operating the Actuator - - - - - - - - - - - - - - - - - - - - - - 6-5
6.1 Actuator Controls
This section describes how to operate a weld cycle using the 2000X aed Actuator. For more
detailed information on making and altering settings, refer to your 2000X-series Power Supply
manual.
When setting up and operating the Actuator, observe the following precautions:
Keep hands away from under the horn. Down force (pressure) and ultrasonic
vibrations can cause injury.
Plastic parts can vibrate within the audible frequency range when welded. If this
occurs, use hearing protectors to prevent possible injury. Do not allow the ultra-
sonically activated horn to touch a metal base or a metal fixture.
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
