100-214-276 Rev. 3 4-9
2000X aed Actuator Chapter 4: Installation and Setup
Instruction Manual Installation Requirements
4.4 Installation Requirements
4.4.1 Location
The actuator or stand may be installed in a variety of positions. The stand (on a base) is often manually oper-
ated, using its base-mounted start switches, and so is installed at a safe and comfortable workbench height
(approximately 30-36 inches) with the operator sitting or standing in front of the system. Stands (on hubs)
are often used in automated systems and may be manually or automatically loaded and unloaded. Actuators
alone can be mounted in any orientation, Contact Branson if mounting upside down.
WARNING!
The stand may tip over if moved around the axis of its column, if not properly secured. The
work surface on which a stand is installed must be sturdy enough to support it, and secure
enough to not tip over when the stand is adjusted during installation or setup.
The power supply may be located up to 25 feet away for the 15kHz, (50' for 20kHz, 20' for 30kHz, and 15'
for 40kHz models) from the actuator. The power supply must be accessible for user parameter changes and
settings, and must be placed in a horizontal orientation. The power supply should be positioned so it does
not draw in dust, dirt or material via its rear fans. Refer to the illustrations on the pages that follow for a
dimensional drawing of each component. All dimensions are approximate and may vary between models:
Figure 4.6
Power Supply Dimensional Drawing on page 4-12
Figure 4.7 2000X Actuator Dimensional Drawing on page 4-13
Figure 4.8 2000X aed 15kHz Actuator Dimensional Drawing on page 4-14
101-240-176 RF, CE - 8’ (J931CS)
101-240-177 RF, CE - 15’ (J931CS)
101-240-178 RF, CE - 25’ (J931CS) Note: Not for 30kHz or 40kHz systems
101-240-199 RF, CE - 50’ (J931C)
101-240-179 RF, CE - 8’ (J934C)
101-240-188 RF, CE - 15’ (J934C)
101-240-182 RF, CE - 20’ (J934C)
100-246-630 Ground Detect Cable
100-143-043 Printer, 6’
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
