100-214-276 Rev. 3 4-35
2000X aed Actuator Chapter 4: Installation and Setup
Instruction Manual Assemble the Acoustic Stack
4.8.3 For a 30kHz System
4.8.4 For a 40kHz System
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Apply a drop of Loctite®
1
290 threadlocker (or equivalent) to the studs for the
booster and horn
1. Loctite is a registered trademark of Henkel Corporation, U.S.A.
3
Install the threaded stud into the top of the booster; torque to 290 in-lbs,
32.76Nm, and let cure for 30 minutes.
4
Install the threaded stud into the top of the horn; torque to 290 in-lbs, 32.76Nm,
and let cure for 30 minutes
5
Install a single Mylar washer (matching the size of the washer to the stud) to
each interface.
6 Screw the converter onto the booster.
7 Torque to 185 in-lbs, 21Nm.
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Apply a drop of Loctite 290 threadlocker (or equivalent) to the studs for the
booster and horn.
3
Install the threaded stud into the top of the booster; torque to 70 in-lbs, 7.91 Nm,
and let cure for 30 minutes.
4
Install the threaded stud into the top of the horn; torque to 70 in-lbs, 7.91 Nm,
and let cure for 30 minutes.
5
Coat each interface surface with a thin film of silicon grease –
but do not apply
silicon grease to a threaded stud or tip.
6 Screw the converter to the booster.
7 Torque to 95 in-lbs, 10.73Nm.
8
Slide the booster/horn assembly into the adapter sleeve. Screw on the adapter
sleeve ring nut and leave loose.
9 Screw the booster onto the horn.
10 Repeat Step 7.
11
Securely tighten the adapter sleeve ring nut with the spanner wrenches shipped
with the sleeve assembly.
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
