100-214-276 Rev. 3 3-3
2000X aed Actuator Chapter 3: Delivery and Handling
Instruction Manual Unpacking
3.3 Unpacking
3.3.1 Actuator Assemblies
Actuator assemblies are heavy and packed in a protective shipping container. The Booster, Con-
verter, and Actuator Toolkit are often packed inside the shipping container.
Each Actuator is shipped as one of the three assemblies described below, with its own corre-
sponding unpacking procedure. These assemblies vary in both the materials used for shipping
and the actual components that you will receive when the Actuator is shipped. For complete
Actuator unpacking and installation procedures, refer to Chapter 4: Installation and Setup.
•Stand (Actuator on Base): A stand consisting of an Actuator on a Base is shipped on a
wooden pallet with a cardboard box cover. (The packaging for this assembly is similar to that
of an Actuator on Hub-Mounted Column.)
•Stand (Actuator on Hub-Mounted Column): A stand consisting of an Actuator on a hub-
mounted column is shipped on a wooden pallet with a cardboard box cover. (The packaging
for this assembly is similar to that of an Actuator on Base.)
•Actuator (Alone): An Actuator that does not use either type of stand is shipped in a rigid
cardboard box using protective foam shells for support.
3.4 Returning Equipment
If you are returning equipment to Branson Ultrasonic Corporation, please call your Customer
Service Representative to receive approval to return goods to Branson.
If you are returning equipment for repair refer to Chapter 1:
Safety and Support, Section 1.5:
Returning Equipment for Repair, of this manual, for appropriate procedure.
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
