4-8 100-214-276 Rev. 3
Chapter 4: Installation and Setup
Take Inventory of Small Parts
4.3.1 Cables
Two cables connect the power supply and actuator: the actuator interface cable, and the RF cable. If the sys-
tem is to be automated, you may also need a J911 start cable and a user I/O cable. Check your invoice for
cable types and cable lengths.
Table 4.2 List of Cables
40kHz Sleeve ordered part ordered part ordered part
40kHz Sleeve Spanner ships w/ Sleeve ships w/ Sleeve ships w/ Sleeve
Fixture Bolts and
Washer
x
M8 Allen Wrench x
101-241-202 Remote Pneumatic (RP) Package Cable (J924), 8’
101-241-203 Actuator Interface, 8’ (J925S)
101-241-204 Actuator Interface, 15’(J925S)
101-241-205 Actuator Interface, 25’(J925S)
101-241-206 Actuator Interface, 50’(J925S)
101-241-207 Alarm I/O, 8’(J957S)
101-241-208 Alarm I/O, 15’(J957S)
101-241-209 Alarm I/O, 25’(J957S)
101-241-258 Alarm I/O, 50’(J957S)
101-240-020 Start Cable (J911) 8’ (req PLA)
101-240-015 Start Cable (J911) 15’ (req PLA)
101-240-010 Start Cable (J911) 25’ (req PLA)
101-240-168 Start Cable (J911) 50’ (req PLA)
101-240-072 Start Cable (J913) 25’ (no PLA req)
101-240-017 RF, non-CE - 8’ (J931S)
101-240-012 RF, non-CE - 15’ (J931S)
101-240-007 RF, non-CE - 25’ (J931S) Note: Not for 30kHz or 40kHz systems
101-240-200 RF, non-CE - 50’ (J931) Note: Not for 30kHz or 40kHz systems
101-240-034 RF, non CE - 8’ (J 934)
101-240-035 RF, non CE - 15’ (J934)
101-240-081 RF, non CE - 8’ (J936S)
101-240-069 RF, non CE - 15’ (J936S)
101-240-080 RF, non CE - 25’ (J936S)
Part or Kit
2000X Power Supply Actuator
15kHz 20kHz 30kHz 40kHz Stand (Base) Stand (Hub) (alone)
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
