100-214-276 Rev. 3 7-9
2000X aed Actuator Chapter 7: Maintenance
Instruction Manual Parts Lists
Assy Regulator 100-246-553
Assy Gauge 100-246-554
Assy RF Conn 100-246-932
ULS Switch Optical 200-099-190
Table 7.4 Accessories List for 2000X aed 15kHz Actuator
Description EDP Number
2000X aed 15kHz Actuator with 3.0-inch diameter cylinder 530-008-232R
Inch Leveling Plate 101-063-358
Metric Ball Bolt (adapts 2000X base to leveling plates) 100-298-085
Metric Leveling Plate 101-063-444
Base, ergo-4” metric, black 580-056-220R
Hub, 2000X for 4” column 101-063-583
Support 4” black 100-246-1311
Column 4’,4” OD X 1/4” wall(China) 580-287-062R
Column 4’,4” OD X 1/4” wall (Danbury) 100-028-011
Column 6’,4” OD X 1/4” wall (option) 100-028-012
CJ-15 Converter 159-135-069
Boosters - 15kHz
Black (Ti), Ratio 1:2.5 101-149-099
Silver (Ti), Ratio 2:1 101-149-098
Gold (Ti), Ratio 1:1.5 101-149-097
Green (Ti), Ratio 1:1 101-149-096
Purple (Ti), Ratio 1:0.6 101-149-095
Gold (Al), Ratio 1:1.5 101-149-080
Green (Al), Ratio 1:1 101-149-079
Purple (Al), Ratio 1:0.6 101-149-087
Table 7.5 Spare Parts List for the 2000X aed 15kHz Actuator
Description EDP Number
Linear Encoder Assembly 100-143-161
Table 7.3 Spare Parts List for the 2000X Actuator (Continued)
Description EDP Number
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
To Next Page
