Chapter 7: Maintenance
Parts Lists
RF Harness Assembly 560-257-230R
S-Beam Assembly 100-246-1276
Cooling Valve Assembly 100-246-896
Base Assembly 560-056-042R
Act-support Assembly(China) 560-164-006R
Act-support Assembly(Danbury) 149-246-1422
Solenoid Valve 100-246-901
Downspeed Control Assembly (Flow Control 1 1/2-2” cyl) 100-246-1310
Downspeed Control Assembly (Flow Control 2 1/2-3” cyl) 100-246-1309
Interface Board Assembly 102-242-717R
ULS Cable Assembly 560-257-232R
Power Light Harness Assembly 560-257-233R
Carriage/Door, 2000X 15kHz 580-121-056R
Assy Cylinder AED– 3.0” Diameter 560-198-009R
Cover AE/AED Actuator, Right 580-101-181R
Cover AE/AED Actuator, Left 580-101-180R
Rod Mech Stop 580-221-005R
Block Mech Stop 580-081-060R
Spring, Compression 890-048-030R
Washer, Flat 890-057-040R
Nut Mtg Mech Stop 580-173-082R
Nut Lock Mech Stop 580-173-083R
Knob Mech Stop 580-263-005R
Bumper Shock Absorber 100-013-019
Scr Set M8X60 580-177-127R
Spring Carriage Ext 580-048-025R
Table 7.5 Spare Parts List for the 2000X aed 15kHz Actuator (Continued)
Description EDP Number
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
To Next Page
