100-214-276 Rev. 3 7-11
2000X aed Actuator Chapter 7: Maintenance
Instruction Manual Parts Lists
Assy Regulator 100-246-553
Assy Gauge 100-246-554
ULS Switch Optical 200-099-190
Rod Mech Stop 580-221-005R
Block Mech Stop 580-081-060R
Spring, Compression 890-048-030R
Washer, Flat 890-057-040R
Nut Mtg Mech Stop 580-173-082R
Nut Lock Mech Stop 580-173-083R
Knob Mech Stop 580-263-005R
Bumper Shock Absorber 100-013-019
Scr Set M8X60 580-177-127R
Spring Carriage Ext 580-048-025R
Assy Regulator 100-246-553
Assy Gauge 100-246-554
ULS Switch Optical 200-099-190
Table 7.5 Spare Parts List for the 2000X aed 15kHz Actuator (Continued)
Description EDP Number
Table 1-1: Suggested Spares
Assembly EDP # 1 - 4 Units 6 - 12 Units 14 + Units
RF Harness 100-246-1282 0 1 2
RF Connector 100-246-932 0 0 1
Linear Encoder 100-143-161 0 0 1
Slide Bearing 200-003-080 0 0 0
Mech. Stop Rod 100-089-066 0 0 0
Block 100-006-197 0 0 0
Insulator 100-062-105 0 0 0
Spring 200-095-138 0 0 0
Mounting Nut 100-073-187 0 0 0
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
