7-8 100-214-276 Rev. 3
Chapter 7: Maintenance
Parts Lists
Downspeed Control Assembly (Flow Control 2 1/2 - 3" cyl) 100-246-1309
Interface Board Assembly 102-242-717R
ULS Cable Assembly 100-241-181
Power Light Harness Assembly 100-246-924
Carriage 2000X Series 100-018-039
Assy Cylinder AED/AOD - 1.5” Diameter 100-246-859
Assy Cylinder AED/AOD - 2.0” Diameter 100-246-858
Assy Cylinder AED/AOD - 2.5” Diameter 100-246-576
Assy Cylinder AED/AOD - 3.0” Diameter 100-246-573
Assy Cylinder AED/AOD - 3.25” Diameter 149-088-859
Door (Metal) 100-037-035
Cover AE/AED Actuator, Right 100-032-444
Cover AE/AED Actuator, Left 100-032-445
MECHANICAL STOPS
Rod Mech Stop 100-089-066
Block Mech Stop 100-006-197
Insulator Teflon Pad 100-062-105
Spring, Compression 200-095-138
Washer, Flat #8 200-114-013
Washer Intl M6 200-114-114
Nut Mtg Mech Stop 100-073-187
Nut Lock Mech Stop 100-073-188
Knob Mech Stop 100-064-054
Bumper Shock Absorber 100-013-019
Scr Set M6 x 6 200-298-102
Spring Carriage Ext 100-095-139
Table 7.3 Spare Parts List for the 2000X Actuator (Continued)
Description EDP Number
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
