Chapter 7: Maintenance
Parts Lists
Hub, 2000X for 4” column 101-063-583
Support 4” black 100-246-1311
Column 4’, 4’’ OD x 1/4” wall 100-028-021
Column 4’, 4” OD x 1/2” wall (option) 100-028-011
Column 6’, 4” OD x 1/2” wall (option) 100-028-012
Sleeve, 1/4” wall column 100-094-159
Sleeve, 1/2” wall column 100-094-102
900 Series Boosters 1/2-20 Input; 1/2-20 Output
Black (Ti), Ratio 1:2.5 101-149-059
Silver (Ti), Ratio 1:2 101-149-058
Gold (Ti), Ratio 1:1.5 101-149-057
Green (Ti), Ratio 1:1 101-149-056
Purple (Ti), Ratio 1:0.6 101-149-060
Silver (Al), Ratio 1:2 101-149-053
Gold (Al), Ratio 1:1.5 101-149-052
Green (Al), Ratio 1:1 101-149-051
Purple (Al), Ratio 1:0.6 101-149-055
Solid Mount Boosters - 20kHz - 1/2-20 Input, 1/2-20 Output
Black (Ti), Ratio 1:2.5 101-149-099
Silver (Ti), Ratio 2:1 101-149-098
Gold (Ti), Ratio 1:1.5 101-149-097
Green (Ti), Ratio 1:1 101-149-096
Purple (Ti), Ratio 1:0.6 101-149-095
Boosters - 30kHz, for use with CA-30 converter
Black (Ti), Ratio 1:2.5 101-149-120
Silver (Ti), Ratio 1:2.0 101-149-121
Gold (Ti), Ratio 1:1.5 101-149-122
Green (Ti), Ratio 1:1 101-149-123
Table 7.2 Accessories List for 2000X aed Actuator (Continued)
Description EDP Number
DOC EXPIRES 12PM 7/24/2012. Article or Material must comply with the requirements
stipulated by RoHS in its current version
