Bredal F4 - Floor Belt Adjustment; Tightening Floor Belts; Correcting Floor Belt Misalignment

58
Normally, the belts do not need to be tightened, unless they are sliding on the rollers
and cannot keep up.
If a oor belt needs to be tightened, tighten the bolts on both sides of the belt one
revolution at a time until the belt is tight enough.
If the belt runs out to one side, adjust it by tightening the nut on the side where the belt
is running out. Tightening the nut with one revolution is usually sucient.
FLOOR BELT ADJUSTMENT
