Installation / Starting
Silver FC 00 511 11
Safety Precautions
RECOMMENDATIONS
• Do not place the edger near or on top of a source of energy (radiator or heater).
• Make sure your voltage source corresponds to the voltage specified on the identification
plate, located at the rear of the machine.
• If the machine is not going to be used for a long period of time you should unplug the power
cords from the wall outlet.
Briot does not assume any responsibilities or liabilities for damages caused by
negligence or ignoring the safety precautions enlisted in this manual.
INSTALLING THE MACHINE
Installation Conditions
Before installing the machine, make sure the bench is made up of the following components:
• The bench
The bench receiving the machine must be steady and level and have a free space
of about 800 x 700 mm.
• The electricity
1 socket: 2P+T - 16 A - 220 V or 110 V protected with a differential circuit breaker
of 30 mA. It is important that the socket be well EARTHED.
• The water
¾A water intake with a stop valve equipped with a 20x27 mm male connector.
This valve must be kept for the machine and drilled at 80 cm maximum from
the place provided for the machine. It must be easily accessible and be closed
when the machine is not in use.
For a well functioning of the machine, the maximum water supply pressure must be
between 4 and 7 bar.
¾A water outlet of 80 mm diameter or greater. The drainage slope must be at least 5%
to ensure proper evacuation of the refuse.
¾For machine type Polycarbonate, provide a place under the machine with a minimum
of 600w x 510h x 460d mm to place the water container.
• The pump
Briot supplies pump systems especially made for the required water supply to Accura
and for filtering of the edging waste, with the following dimensions.
9 Width: 600 mm (24”)
9 Depth: 400 mm (16”)
9 Height: 800 mm (32”).
