Installation / Starting
12 Silver FC 00 511
Work bench preparation
Follow the steps below to prepare the bench.
Step Action
1
Drill the bench as shown in the following diagram:
305 mm
270 mm
∅ 120 mm
660 mm
Bench
Edger
598 mm
2
Drill the drain water hole(s).
3
Place the edger on the bench by positioning it in relation to the drilled holes.
Installation
Follow the steps below to install the machine.
Step Action
1
Level the machine by screwing or unscrewing
the four feet.
2
Plug the drain pipe to the chassis of the machine.
3
Connect the water intake hose(s) to the machine
and to the faucet or the pump.
Note
: In case of installation on direct water only,
add a filter joint contained in the accessory box.
