2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Hardware Signal Descriptions
Broadcom Corporation
Document 7405-1HDM00-R Pin Definition Notations Page 1-129
1 20 - D1.2V VDDC V V 1.2 – AC22 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC23 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AA12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – R12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – T12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – U12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AA11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – T11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – U11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB11 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V23 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W23 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y23 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AA23 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB23 Digital Power Supply (1.2V
core ±5%)
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
