BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-130 Pin Definition Notations Document 7405-1HDM00-R
1 20 - D1.2V VDDC V V 1.2 – AA24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – U24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB24 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AA10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – P12 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – T10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – U10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB10 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AE25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AD25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AB25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – V25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – W25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – Y25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AA25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AC25 Digital Power Supply (1.2V
core ±5%)
1 20 - D1.2V VDDC V V 1.2 – AE16 Digital Power Supply (1.2V
core ±5%)
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
