2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Hardware Signal Descriptions
Broadcom Corporation
Document 7405-1HDM00-R Pin Definition Notations Page 1-139
1 21 - DGND/AGND DVSS G G – – R29 Digital Ground
1 21 - DGND/AGND DVSS G G – – E31 Digital Ground
1 21 - DGND/AGND DVSS G G – – AJ11 Digital Ground
1 21 - DGND/AGND DVSS G G – – AG6 Digital Ground
1 21 - DGND/AGND DVSS G G – – AG7 Digital Ground
1 21 - DGND/AGND DVSS G G – – L24 Digital Ground
Analog Ground Balls - 91
1 21 - DGND/AGND CLK54_XVSS G G – – J28 Analog Ground
1 21 - DGND/AGND CLK54_XVSS G G – – R23 Analog Ground
1 21 - DGND/AGND CLK54_XVSS G G – – P24 Analog Ground
1 21 - DGND/AGND CLK54_XVSS G G – – N25 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – K25 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – L25 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – M25 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – M24 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – N24 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – P23 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – H28 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – G29 Analog Ground
1 21 - DGND/AGND UHF_AVSS G G – – N23 Analog Ground
1 21 - DGND/AGND RFM_AVSS G G – – K23 Analog Ground
1 21 - DGND/AGND RFM_AVSS G G – – L23 Analog Ground
1 21 - DGND/AGND RFM_AVSS G G – – M23 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – K21 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – K22 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – L21 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – L22 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – M20 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – M21 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – M22 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – F22 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – G22 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – F25 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – F23 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – G23 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – F24 Analog Ground
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
