2/24/2008 9T6WP
BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-140 Pin Definition Notations Document 7405-1HDM00-R
1 21 - DGND/AGND VDAC_AVSS G G – – G24 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – N20 Analog Ground
1 21 - DGND/AGND VDAC_AVSS G G – – N21 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – K19 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – K20 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – L19 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – L20 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – M19 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – F20 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – G20 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – F21 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – G21 Analog Ground
1 21 - DGND/AGND AUD_AVSS G G – – N19 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – K17 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – K18 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – L17 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – L18 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – M18 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – F17 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – G17 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – F18 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – G18 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – F19 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – G19 Analog Ground
1 21 - DGND/AGND HDMI_AVSS G G – – N18 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – K15 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – L15 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – K16 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – L16 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – M16 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – F14 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – G14 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – F15 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – F16 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – G15 Analog Ground
1 21 - DGND/AGND EPHY_AVSS G G – – G16 Analog Ground
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
