BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-142 Pin Definition Notations Document 7405-1HDM00-R
1 DEPOP – – – – AP9 Depopulated Balls
1 DEPOP – – – – AP12 Depopulated Balls
1 DEPOP – – – – AP18 Depopulated Balls
1 DEPOP – – – – AP24 Depopulated Balls
1 DEPOP – – – – AP27 Depopulated Balls
1 DEPOP – – – – AP30 Depopulated Balls
1 DEPOP – – – – AK1 Depopulated Balls
1 DEPOP – – – – AG1 Depopulated Balls
1 DEPOP – – – – AD1 Depopulated Balls
1 DEPOP – – – – AA1 Depopulated Balls
1 DEPOP – – – – J1 Depopulated Balls
1 DEPOP – – – – F1 Depopulated Balls
1 DEPOP – – – – AJ34 Depopulated Balls
1 DEPOP – – – – AF34 Depopulated Balls
1 DEPOP – – – – AC34 Depopulated Balls
1 DEPOP – – – – U34 Depopulated Balls
1 DEPOP – – – – P34 Depopulated Balls
1 DEPOP – – – – L34 Depopulated Balls
1 DEPOP – – – – H34 Depopulated Balls
1 DEPOP – – – – E34 Depopulated Balls
1 DEPOP – – – – AP15 Depopulated Balls
1 DEPOP – – – – AP21 Depopulated Balls
1 DEPOP – – – – V1 Depopulated Balls
1 DEPOP – – – – A20 Depopulated Balls
1 DEPOP – – – – Y34 Depopulated Balls
1 DEPOP – – – – AG8 Depopulated Balls
1 DEPOP – – – – L27 Depopulated Balls
1 DEPOP – – – – AG9 Depopulated Balls
1 DEPOP – – – – AF10 Depopulated Balls
1 DEPOP – – – – AG10 Depopulated Balls
1 DEPOP – – – – AF11 Depopulated Balls
1 DEPOP – – – – AG11 Depopulated Balls
1 DEPOP – – – – AF12 Depopulated Balls
1 DEPOP – – – – AG12 Depopulated Balls
1 DEPOP – – – – AF13 Depopulated Balls
1 DEPOP – – – – AG13 Depopulated Balls
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
