Broadcom BCM7405 - Page 157

2/24/2008 9T6WP
Preliminary Hardware Data Module BCM7405
06/29/07 Hardware Signal Descriptions
Broadcom Corporation
Document 7405-1HDM00-R Pin Definition Notations Page 1-143
1 DEPOP – – – – AF14 Depopulated Balls
1 DEPOP – – – – AG14 Depopulated Balls
1 DEPOP – – – – AF15 Depopulated Balls
1 DEPOP – – – – AG15 Depopulated Balls
1 DEPOP – – – – AF16 Depopulated Balls
1 DEPOP – – – – AG16 Depopulated Balls
1 DEPOP – – – – AF17 Depopulated Balls
1 DEPOP – – – – AG17 Depopulated Balls
1 DEPOP – – – – AF18 Depopulated Balls
1 DEPOP – – – – AG18 Depopulated Balls
1 DEPOP – – – – AF19 Depopulated Balls
1 DEPOP – – – – AG19 Depopulated Balls
1 DEPOP – – – – AF20 Depopulated Balls
1 DEPOP – – – – AG20 Depopulated Balls
1 DEPOP – – – – AF21 Depopulated Balls
1 DEPOP – – – – AG21 Depopulated Balls
1 DEPOP – – – – AF22 Depopulated Balls
1 DEPOP – – – – AG22 Depopulated Balls
1 DEPOP – – – – AF23 Depopulated Balls
1 DEPOP – – – – AG23 Depopulated Balls
1 DEPOP – – – – AF24 Depopulated Balls
1 DEPOP – – – – AG26 Depopulated Balls
1 DEPOP – – – – AG24 Depopulated Balls
1 DEPOP – – – – M26 Depopulated Balls
1 DEPOP – – – – AG27 Depopulated Balls
1 DEPOP – – – – H9 Depopulated Balls
1 DEPOP – – – – H10 Depopulated Balls
1 DEPOP – – – – J9 Depopulated Balls
1 DEPOP – – – – J10 Depopulated Balls
1 DEPOP – – – – K8 Depopulated Balls
1 DEPOP – – – – K9 Depopulated Balls
1 DEPOP – – – – M8 Depopulated Balls
1 DEPOP – – – – L8 Depopulated Balls
1 DEPOP – – – – L9 Depopulated Balls
1 DEPOP – – – – N8 Depopulated Balls
1 DEPOP – – – – P8 Depopulated Balls
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
