BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-144 Pin Definition Notations Document 7405-1HDM00-R
1 DEPOP – – – – R8 Depopulated Balls
1 DEPOP – – – – T8 Depopulated Balls
1 DEPOP – – – – T9 Depopulated Balls
1 DEPOP – – – – U8 Depopulated Balls
1 DEPOP – – – – U9 Depopulated Balls
1 DEPOP – – – – V8 Depopulated Balls
1 DEPOP – – – – V9 Depopulated Balls
1 DEPOP – – – – W8 Depopulated Balls
1 DEPOP – – – – W9 Depopulated Balls
1 DEPOP – – – – Y8 Depopulated Balls
1 DEPOP – – – – Y9 Depopulated Balls
1 DEPOP – – – – AA8 Depopulated Balls
1 DEPOP – – – – AA9 Depopulated Balls
1 DEPOP – – – – AB8 Depopulated Balls
1 DEPOP – – – – AB9 Depopulated Balls
1 DEPOP – – – – AC8 Depopulated Balls
1 DEPOP – – – – AC9 Depopulated Balls
1 DEPOP – – – – AD8 Depopulated Balls
1 DEPOP – – – – AD9 Depopulated Balls
1 DEPOP – – – – AE8 Depopulated Balls
1 DEPOP – – – – AE9 Depopulated Balls
1 DEPOP – – – – AF8 Depopulated Balls
1 DEPOP – – – – AF9 Depopulated Balls
1 DEPOP – – – – AD27 Depopulated Balls
1 DEPOP – – – – AF26 Depopulated Balls
1 DEPOP – – – – AE27 Depopulated Balls
1 DEPOP – – – – AF25 Depopulated Balls
1 DEPOP – – – – AF27 Depopulated Balls
1 DEPOP – – – – AG25 Depopulated Balls
1 DEPOP – – – – Y27 Depopulated Balls
1 DEPOP – – – – AB26 Depopulated Balls
1 DEPOP – – – – AA27 Depopulated Balls
1 DEPOP – – – – AC26 Depopulated Balls
1 DEPOP – – – – AB27 Depopulated Balls
1 DEPOP – – – – AD26 Depopulated Balls
1 DEPOP – – – – AC27 Depopulated Balls
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
