Preliminary Hardware Data Module BCM7405
06/29/07 Hardware Signal Descriptions
Broadcom Corporation
Document 7405-1HDM00-R Pin Definition Notations Page 1-145
1 DEPOP – – – – AE26 Depopulated Balls
1 DEPOP – – – – T27 Depopulated Balls
1 DEPOP – – – – V26 Depopulated Balls
1 DEPOP – – – – U27 Depopulated Balls
1 DEPOP – – – – W26 Depopulated Balls
1 DEPOP – – – – V27 Depopulated Balls
1 DEPOP – – – – Y26 Depopulated Balls
1 DEPOP – – – – W27 Depopulated Balls
1 DEPOP – – – – AA26 Depopulated Balls
1 DEPOP – – – – L26 Depopulated Balls
1 DEPOP – – – – P26 Depopulated Balls
1 DEPOP – – – – N27 Depopulated Balls
1 DEPOP – – – – R26 Depopulated Balls
1 DEPOP – – – – P27 Depopulated Balls
1 DEPOP – – – – T26 Depopulated Balls
1 DEPOP – – – – R27 Depopulated Balls
1 DEPOP – – – – U26 Depopulated Balls
1 DEPOP – – – – H11 Depopulated Balls
1 DEPOP – – – – H12 Depopulated Balls
1 DEPOP – – – – H13 Depopulated Balls
1 DEPOP – – – – J11 Depopulated Balls
1 DEPOP – – – – H14 Depopulated Balls
1 DEPOP – – – – J12 Depopulated Balls
1 DEPOP – – – – H15 Depopulated Balls
1 DEPOP – – – – J13 Depopulated Balls
1 DEPOP – – – – H16 Depopulated Balls
1 DEPOP – – – – J14 Depopulated Balls
1 DEPOP – – – – H17 Depopulated Balls
1 DEPOP – – – – J15 Depopulated Balls
1 DEPOP – – – – H18 Depopulated Balls
1 DEPOP – – – – J16 Depopulated Balls
1 DEPOP – – – – H19 Depopulated Balls
1 DEPOP – – – – J17 Depopulated Balls
1 DEPOP – – – – H20 Depopulated Balls
1 DEPOP – – – – J18 Depopulated Balls
1 DEPOP – – – – H21 Depopulated Balls
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
