BCM7405 Preliminary Hardware Data Module
Hardware Signal Descriptions 06/29/07
Broadcom Corporation
Page 1-146 Pin Definition Notations Document 7405-1HDM00-R
1 DEPOP – – – – J19 Depopulated Balls
1 DEPOP – – – – H22 Depopulated Balls
1 DEPOP – – – – J20 Depopulated Balls
1 DEPOP – – – – H23 Depopulated Balls
1 DEPOP – – – – J21 Depopulated Balls
1 DEPOP – – – – H24 Depopulated Balls
1 DEPOP – – – – J22 Depopulated Balls
1 DEPOP – – – – H25 Depopulated Balls
1 DEPOP – – – – J23 Depopulated Balls
1 DEPOP – – – – H26 Depopulated Balls
1 DEPOP – – – – J24 Depopulated Balls
1 DEPOP – – – – H27 Depopulated Balls
1 DEPOP – – – – J25 Depopulated Balls
1 DEPOP – – – – J26 Depopulated Balls
1 DEPOP – – – – K26 Depopulated Balls
1 DEPOP – – – – J27 Depopulated Balls
1 DEPOP – – – – K27 Depopulated Balls
1 DEPOP – – – – N26 Depopulated Balls
1 DEPOP – – – – M27 Depopulated Balls
1 DEPOP – – – – H8 Depopulated Balls
1 DEPOP – – – – J8 Depopulated Balls
1 DEPOP – – – – M9 Depopulated Balls
1 DEPOP – – – – N9 Depopulated Balls
1 DEPOP – – – – P9 Depopulated Balls
1 DEPOP – – – – R9 Depopulated Balls
1 DEPOP – – – – R1 Depopulated Balls
1 DEPOP – – – – M1 Depopulated Balls
Table 1-19: Pin Descriptions (Cont.)
# of
Pins
Orcad Schematic
Block
Label I/O Res.
Tol.
(V)
Drv.
(mA)
Loc. Description
