PoE Firmware files (Continued)TABLE 41
Product PoE Firmware
FCX fcx_poeplus_02.1.0.b004.fw
ICX 64xx icx64xx_poeplus_02.1.0.b004.fw
ICX 6450-C12 icx64xxc12_poeplus_02.03.09.fw
ICX 6610 fcx_poeplus_02.1.0.b004.fw
ICX 7250 icx72xx_poeplus_01.6.1.b009.fw
ICX 7450 icx74xx_poh_01.6.1.b009.fw
Installing PoE firmware with TFTP
PoE firmware is stored in the PoE controller of the FastIron switch. You can install PoE firmware from
the TFTP server on a FastIron switch using CLI commands. To do so, you should have a valid firmware
image on the TFTP server.
NOTE
The PoE firmware upgrade feature is not supported in FIPS mode on Brocade devices.
NOTE
You can install PoE firmware only on one switch at a time. To install PoE firmware on stacked units, you
need to install it individually on every switch in the stack.
NOTE
The CLI syntax to install PoE firmware is different on FSX, FCX, and ICX platforms.
NOTE
Installation of PoE firmware interrupts PoE services on the individual device or module as it is
upgraded. PoE service restarts once PoE firmware installation is complete.
1. Place the PoE firmware on a TFTP server to which the Brocade device has access.
2. Copy the PoE firmware from the TFTP server into the switch as shown in the following examples. Be
sure to use the correct file image for the platform.
To install PoE firmware on FCX and ICX platforms, use the inline power install-firmware stack-
unit command as shown in the following example.
device# inline power install-firmware stack-unit 1 tftp 10.120.54.161
fcx_poeplus_07400.fw
Syntax: inline power install-firmware [stack-unit |unit-number] tftp ip-address filename
Installing PoE firmware with TFTP
FastIron Ethernet Switch Administration Guide 347
53-1003625-01
