Field definitions for the show inline power pd command (Continued)TABLE 44
Column Definition
Total PD Power
Switched to PSE
Total PD power switched to PSE. It is either 0 or the total available power.
Port The port number of the PD port.
Oper State The operational state of the PD port. This value can be one of the following:
• On - The PD port is linked to a PSE port and is consuming power.
• Off - The PD port is not linked to a PSE port and is not consuming power.
Oper Mode The operational mode of the PD port. This value is meaningful if Oper State is On. This
value can be one of the following:
• 802.3af - The PD port is operating in the AF mode.
• 802.3at - The PD port is operating in the AT mode.
• n/a - The PD port is not operational.
Fault/Error Shows the error or fault conditions affecting the PD port. This value can be one of the
following:
• An error or fault code is displayed.
• n/a - No error or fault condition on the PD port.
Displaying detailed information about PoE power supplies
The show inline power detail command displays detailed operational information about the PoE
power supplies in FastIron PoE switches. The command output differs on FCX POE+ switches
compared to FSX Series and ICX switches.
The following is an example of the show inline power detail command output on an FCX POE+
switch.
device# show inline power detail
Power Supply Data On stack 1:
++++++++++++++++++
Power Supply #1:
Max Curr: 7.5 Amps
Voltage: 54.0 Volts
Capacity: 410 Watts
POE Details Info. On Stack 1 :
General PoE Data:
+++++++++++++++++
Firmware
Version
--------
02.1.0
Cumulative Port State Data:
+++++++++++++++++++++++++++
#Ports #Ports #Ports #Ports #Ports #Ports #Ports
Admin-On Admin-Off Oper-On Oper-Off Off-Denied Off-No-PD Off-Fault
-------------------------------------------------------------------------
45 3 0 48 0 45 0
Cumulative Port Power Data:
+++++++++++++++++++++++++++
#Ports #Ports #Ports Power Power
Pri: 1 Pri: 2 Pri: 3 Consumption Allocation
-----------------------------------------------
0 0 45 0.0 W 0.0 W
Power Supply Data On stack 2:
Displaying detailed information about PoE power supplies
364 FastIron Ethernet Switch Administration Guide
53-1003625-01
