Field definitions for the show inline power detail command (Continued)TABLE 45
Column Definition
Cumulative port state data
NOTE
When you enable a port using the CLI, it may take 12 or more seconds before the operational state of that port is
displayed correctly in the show inline power output.
Slot The Interface device/slot/port number.
#Ports Admin-On The number of ports on the Interface module on which the inline power command
was issued.
#Ports Admin-Off The number of ports on the Interface module on which the inline power command
was not issued.
#Ports Oper-On The number of ports on the Interface module that are receiving inline power from
the PoE power supply.
#Ports Oper-Off The number of ports on the Interface module that are not receiving inline power
from the PoE power supply.
#Ports Off-Denied The number of ports on the Interface module that were denied power because of
insufficient power.
#Ports Off-No-PD The number of ports on the Interface module to which no PDs are connected.
#Ports Off-Fault The number of ports on the Interface module that are not receiving power because
of a subscription overload.
Total The totals for all of the fields in the Cumulative Port State Data report.
Cumulative port power data
Slot The device/slot/port number.
#Ports Pri: 1 The number of PoE ports on the Interface module that have a PoE port priority of 1.
#Ports Pri: 2 The number of PoE ports on the Interface module that have a PoE port priority of 2.
#Ports Pri: 3 The number of PoE ports on the Interface module that have a PoE port priority of 3.
Power Consumption The total number of watts consumed by PoE power consuming devices, plus any
cable loss.
Power Allocation The number of watts allocated to the Interface module PoE ports. This value is the
sum of the ports’ default or configured maximum power levels, or power classes
automatically detected by the FastIron PoE device.
Power over Ethernet
370 FastIron Ethernet Switch Administration Guide
53-1003625-01
