The following example checks for ports with active breakout configuration and then removes breakout
from ports 1/3/1 through 1/3/6.
Device# show breakout
Unit-Id: 1
Port Module Exist Module Conf breakout_conf breakout_oper
1/1/5 Yes No Yes Yes
1/1/6 Yes No Yes Yes
1/1/7 Yes No Yes Yes
1/1/8 Yes No Yes Yes
1/1/9 Yes No Yes Yes
1/1/10 Yes No Yes Yes
1/1/11 Yes No Yes Yes
1/1/12 Yes No Yes Yes
1/1/13 Yes No Yes Yes
1/1/14 Yes No Yes Yes
1/1/15 Yes No Yes Yes
1/1/16 Yes No Yes Yes
1/2/1 Yes No Yes Yes
1/2/2 Yes No Yes Yes
1/2/3 Yes No Yes Yes
1/2/4 Yes No Yes Yes
1/2/5 Yes No Yes Yes
1/2/6 Yes No Yes Yes
1/3/1 Yes No Yes Yes
1/3/2 Yes No Yes Yes
1/3/3 Yes No Yes Yes
1/3/4 Yes No Yes Yes
1/3/5 Yes No Yes Yes
1/3/6 Yes No Yes Yes
Device# configure terminal
Device(config)# no breakout ethernet 1/3/1 to 1/3/6
Reload required. Please write memory and then reload or power cycle.
Device(config)# write memory
Write startup-config done.
Device(config)# Flash Memory Write (8192 bytes per dot) .
Copy Done.
Device(config)# end
Device# reload
NOTE
If there had been any configuration on any sub-ports (1/3/1:1 to 1/3/6:4), the no
breakout command would have returned an error. The configuration would
then have to be removed from the sub-ports before breakout configuration
could be removed.
The following example shows a failed attempt to remove breakout from port
1/1/5 as indicated by the error message. Configuration is then removed from
sub-port 1/1/5:1 before the breakout configuration is successfully removed.
Once the updated configuration is loaded, the ports are restored as full 40 Gbps
ports. The former sub-port configuration is not retained in memory.
device(config)# no breakout ethernet 1/1/5
Error: Port 1/1/5:1 is tagged
device(config)# vlan 200
device(config-vlan-200)# no tagged ethernet 1/1/5:1
Deleted tagged port(s) to port-vlan 200.
device(config)# end
device# configure terminal
device(config)# no breakout ethernet 1/1/5
Reload required. Please write memory and then reload or power cycle.
device(config)# end
device# write memory
Write startup-config done.
40 Gbps Breakout Ports
382 FastIron Ethernet Switch Administration Guide
53-1003625-01
