180 Brocade MLX Series and NetIron XMR Hardware Installation Guide
53-1003821-01
Installing a NetIron XMR 32000 router
3
FIGURE 122 Routing upper-left quadrant cables up
1 Upper left quadrant 3 Cables from slot #1
2 Side combs (18) 4 Cables from slot #2
2
4
1
3
