Managing the cooling system
6
Changing the temperature polling interval
By default, the router reads the temperature sensor on each module every 60 seconds. To change
the polling interval, enter the temp-poll-period command at the global CONFIG level of the CLI.
Brocade(config)# temp-poll-period 120
Syntax: temp-poll-period <seconds>
For the seconds parameter, you can specify a value from 30 – 120.
LP Sensor 2 reading (TM 0) THERMAL_SENSOR_TEST_RULE_LP_XPP N/A (Must not be changed)
LP Sensor 3
a
reading (TM 1) THERMAL_SENSOR_TEST_RULE_LP fan-threshold lp
LP Sensor 4
b
reading (TM 1) THERMAL_SENSOR_TEST_RULE_LP_XPP N/A (Must not be changed)
NI-MLX-10Gx8-M LP Modules
LP2 Sensor 1 reading THERMAL_SENSOR_TEST_RULE_LP_2 fan-threshold lp2
LP2 Sensor 2 reading THERMAL_SENSOR_TEST_RULE_LP_XPP2 N/A (Must not be changed)
LP2 Sensor 3 reading UNUSED UNUSED
LP2 Sensor 4 reading THERMAL_SENSOR_TEST_RULE_LP_2 fan-threshold lp2
LP2 Sensor 5 reading THERMAL_SENSOR_TEST_RULE_LP_XPP2 N/A (Must not be changed)
LP2 Sensor 6 reading UNUSED UNUSED
LP2 Sensor 7 reading UNUSED UNUSED
BR-MLX-100Gx2-X LP Modules
LP2 Sensor 1 reading THERMAL_SENSOR_TEST_RULE_LP_2 fan-threshold lp2
LP2 Sensor 2 reading THERMAL_SENSOR_TEST_RULE_LP_XPP2 N/A (Must not be changed)
LP2 Sensor 3 reading UNUSED UNUSED
LP2 Sensor 4 reading THERMAL_SENSOR_TEST_RULE_LP_2 fan-threshold lp2
LP2 Sensor 5 reading THERMAL_SENSOR_TEST_RULE_LP_XPP2 N/A (Must not be changed)
LP2 Sensor 6 reading UNUSED UNUSED
LP2 Sensor 7 reading UNUSED UNUSED
LP2 Sensor 8 reading UNUSED UNUSED
LP2 Sensor 9 reading UNUSED UNUSED
LP2 Sensor 10 reading UNUSED UNUSED
LP2 Sensor 11 reading UNUSED UNUSED
LP2 Sensor 12 reading UNUSED UNUSED
a. The four sensors may be displayed in the show chassis command output as Sensor1, Sensor2, Sensor4, and
Sensor5. In that case, Sensor4 and Sensor 5 refer to the LP and LP XPP sensors on the second traffic manager, TM 1.
b. The four sensors may be displayed in the show chassis command output as Sensor1, Sensor2, Sensor4, and
Sensor5. In that case, Sensor4 and Sensor 5 refer to the LP and LP XPP sensors on the second traffic manager, TM 1.
TABLE 39 Associations between show chassis, show fan threshold, and fan-threshold commands (Continued)
show chassis command output
(sensors)
show fan-threshold command output
(thermal block)
fan-threshold command
configuration
