Brocade Communications Systems MLX Series Hardware Installation Guide

Brocade MLX Series and NetIron XMR Hardware Installation Guide 13
53-1003821-01
Router modules
1
• Connecting to the 10BaseT, 100BaseTX, or 1000BaseTX port for connectivity to your existing
management network. You can then access the router and configure, monitor, and manage the
system from a management station.
NOTE
The existing management network into which you can connect the 10/100/1000 Ethernet port
must be separate and isolated from the network over which user packets are switched and routed.
For information about the functionality of the management port, refer to “Understanding
management port functions” on page 217.
For information about connecting a PC to the 10/100/1000 Ethernet port, refer to “Attaching a
management station” on page 122.
The out-of-band management port provides access to a separate system management network,
and allows you to do the following tasks:
• Access the router through Telnet, the Web management interface, or the Brocade Network
Advisor software.
• Access a TFTP server to perform system upgrade tasks.
• Provides SNMP polling access, as well as sending SNMP traps.
• Send Syslog packets.
• Access the system through RADIUS AAA.
Management module LEDs
The LEDs on all management module models are the same. Table 2 describes the LEDs on the
management module.
TABLE 2 Management module LEDs
LED Position State Meaning
Port 1
and
Port 2
Each adjacent to
the auxiliary flash
slot that it
represents
On or blinking The software is currently accessing the auxiliary
flash card.
Off The software is not currently accessing a auxiliary
flash card, although there is one inserted in the slot.
Active Lower Left On The module is functioning as the active
management module.
Off The module is functioning as the redundant
management module.
Pwr Upper Left On The module is receiving power.
Off The module is not receiving power.
10/100/1000
Ethernet Port
Above and right of
RJ45 connector
On (Green) A link is established with the remote port.
Off No link is established with the remote port.
10/100/1000
Ethernet Port
Above and left of
RJ45 connector
On or blinking
(Yellow)
The port is transmitting and receiving packets.
Off for an
extended period
The port is not transmitting or receiving packets.
