Brocade MLX Series and Brocade NetIron XMR Hardware Installation Guide 371
53-1002373-02
Replacing fan assemblies
8
FIGURE 242 Air filter removal and replacement for a Brocade MLX or Brocade NetIron XMR 4-slot router.
FIGURE 243 Air filter removal and replacement for the 8-slot router.
3. Pull the old air filter out of the router and discard it.
4. Insert the replacement air filter by sliding it along the metal guides.
The filter is marked with an arrow that indicates how the filter should be installed for proper
airflow in the device. Since air is pulled through the router, the arrow must point right towards
the fan tray.
5. Push the filter retainer into the router and tighten the two screws.
1 Direction of airflow in device 3 Filter retainer
2Filter 4Fan trap
1 Direction of airflow in device 3 Filter retainer
2Filter 4Fan trap
1
2
3
4
1
2
3
4
