• Use show chassis command to determine if you need additional power supplies.
• For installation in an MLXe-32 chassis, congure the chassis dierently based on whether it has a Gen-1 module or not.
• The following conditions may prevent a BR-MLX-10Gx24-DM interface module from coming up properly:
– BR-MLX-10Gx24-DM interface modules require the snmp-server max-index-per-module 40|64 congured.
Otherwise, the cards will not come up.
NOTE
Not all features available in NetIron R05.4.00 are supported on the BR-MLX-10Gx24-DM interface module. To verify if a
particular feature is supported with the BR-MLX-10Gx24-DM interface module, refer to the latest version of the Multi-Service
IronWare Conguration Guide
NOTE
For maximum performance, you must operate your BR-MLX-10Gx24-DM interface module with high speed switch fabric
modules in turbo mode. For information on switch fabric modules, refer to Managing switch fabric modules on page 209.
Installation procedure
When installing modules, wear an ESD wrist strap with a plug for connection to the ESD connector on the router chassis or other suitable
ground.
DANGER
For safety reasons, the ESD wrist strap should contain a 1 megohm series resistor.
1. Upgrade the software on all management modules and interface modules to Multi-Service IronWare R05.4.00 or later. For
specic upgrade instructions, refer to the Multi-Service IronWare Upgrade Guide.
2. Congure the snmp maximum interface index per module to 64 using the snmp-server max-index-per-module 64
command
device (config)# snmp-server max-ifindex-per-module 64
3. For MLXe-32 installations only:
a) If the chassis has a Gen-1 module, enter the following commands.
device# config
device(config)# system-init mlxe32-24x10g-enable max-tm-queue-4
device(config)# system-init fabric-data-mode force-normal
device# write memory
device# reload
b) If the chassis has no Gen-1 module, enter the following commands.
device# config
device(config)# system-init mlxe32-24x10g-enable
device# write memory
device# reload
4. Install the BR-MLX-24x10G-DM module.
5. Verify that the module comes up,
NOTE
For known limitations, please refer to the Release Notes shipped with your module.
Installing BR-MLX-10Gx24-DM interface modules in Brocade MLXe Series routers
Brocade NetIron MLXe Series Hardware Installation Guide
92 53-1004203-04
