Mounting Brocade MLXe Series-4, -8, or -16 routers
in a 4-post EIA rack
EIA rack or 4-Post Rack Mount Kit contents
You can mount Brocade MLXe Series routers in a EIA rack or 4-post rack using the optional EIA rack/4-post rack mount kits available
from Brocade. The following table lists these kits and their contents.
TABLE 31 EIA rack/4-Post Rack Mount Kits for Brocade MLXe Series-4, MLXe-8, and MLXe-16 routers
Contents for RMK-CAB-MLXE-4 Contents for RMK-CAB-MLXE-8 Contents for RMK-CAB-MLXE-16
Front bracket left A (1)
Front bracket right B (1)
Left side plate A (1)
Right side plate (B 1)
2U shelf assembly (1)
Adjustable top rail (1)
Rail extender for top rail, 27-29" (1)
Rail extender for top rail, 29-31" (1)
Thermal duct (1)
Right transport bracket, 27-29" (1)
Left transport bracket, 27-29" (1)
Right transport bracket, 29-31" (1)
Left transport bracket, 29-31" (1)
Alignment washers (4)
Phillips pan-head screws, 10-32x.63", square
cone (30)
Floating clip nut, 10-32 (26)
Retainer nut, 10-32 (26)
Snap plastic rivets (12)
Phillips at-head screws, 6-32x1/4" (10)
Screws, 6-32, 1/4" Phillips at-head, zinc, black
(18)
Screws, 10-32, 1/4" Phillips at-head,
100Deg, steel, black (16)
Front bracket left A (1)
Front bracket right B (1)
Left side plate A (1)
Right side plate B (1)
2U shelf assembly (1)
Adjustable top rail (1)
Rail extender for top rail, 27-29" (1)
Rail extender for top rail, 29-31" (1)
Thermal duct (1)
Right transport bracket, 27-29" (1)
Left transport bracket, 27-29" (1)
Right transport bracket, 29-31" (1)
Left transport bracket, 29-31" (1)
Alignment washers (4)
Phillips pan-head screws, 10-32x.63", square
cone (30)
Floating clip nut, 10-32 (26)
Retainer nut, 10-32 (26)
Snap plastic rivets (12)
Phillips at-head screws, 6-32x1/4" (10)
Screws, 6-32, 1/4" Phillips at-head, zinc, black
(18)
Screws, 10-32, 1/4" Phillips at-head,
100Deg, steel, black (16)
Front bracket left A (1)
Front bracket right B (1)
Left side plate A (1)
Right side plate B (1)
Chassis alignment rail ((1)
Air block shelf (1)
Phillips at-head screws, 6-32x1/4" (10)
Snap plastic rivets (12)
Right transport bracket, 27-29" (1)
Left transport bracket, 27-29" (1)
Right transport bracket, 29-31" (1)
Left transport bracket, 29-31" (1)
Alignment washers (4)
Phillips pan-head screws, 10-32x.63", square
cone (30)
Floating clip nut, 10-32 (26)
Retainer nut, 10-32 (26)
Screws, 6-32, 1/4" Phillips at-head, zinc, black
(18)
Screws, 10-32, 1/4" Phillips at-head,
100Deg, steel, black (16)
Installing Brocade MLXe Series-4 and Brocade MLXe Series-8 routers in
a 4-post EIA rack
This section describes how to install Brocade MLXe Series-4 or MLXe-8 routers in a 4-post EIA rack using the RMK-CAB-MLXE-4 or
RMK-CAB-MLXE-8 4-Post Rack Mount Kits.
Mounting Brocade MLXe Series-4, -8, or -16 routers in a 4-post EIA rack
Brocade NetIron MLXe Series Hardware Installation Guide
53-1004203-04 121
