Operation Manual
FT1020G3 Rev 2.4
147
31 FDCIE Maintenance
The FDCIE shall be maintained and tested in accordance with the Australian standard
AS1851.
To avoid the Fault TX output(s) to be activated, they can be disabled via menu H2/B5 (or
via an open door, see chapter "Open door” page 47. However, in Australia the routing
equipment must be isolated via the ASE.
Regarding the fault condition, see chapter "Fault", page 61 and "Fault messages", page
62.
Note: Most of the faults have approximately 60 seconds delay.
Each Control Unit should be tested as follows:
• Perform monthly / quarterly / yearly test (menu H1).
• Remove one battery fuse (e.g. F2 on the Main board 5010). The following fault
message is to be shown:
FAULT: Battery not connected CU xx
Note: xx is dependent on Control Unit (xx=00-29).
• Re-place the fuse and acknowledge the fault (menu H6).
• Remove fuse F4 on the Main board 5010.
The following fault message is to be shown:
FAULT: Supervised output 0, CU xx
Note: xx is dependent on Control Unit (xx=00-29).
31.1 Replacing Printer Paper
If a printer is available the soft key " Print" is shown and can be used to start a print-out.
During printing the same soft key might change to " Abort printing ".
NOTE! After pressing the soft key " Abort printing " it will change back to " Print " but the
printing might continue for a few seconds.
When the paper roll is almost empty, a red line appears on one edge of the paper. Change
the paper roll before it is completely empty! Always have a spare paper roll on site (paper
width 58 mm).
Change the paper roll as follows:
• Read all instructions before changing the paper roll.
• Open the Control Unit acrylic door.
• Open the printer cover, i.e. press the green illuminated release button (in the
middle) on top of the printer front.
• Remove the remainder of the old paper roll.
• Place the new paper roll in the printer. Make sure the paper rolls in the proper
direction – same as the old one.
• Pull out 50 mm paper and close the cover.
• Tear off the paper, then press the Paper feed button (to the right) on top of the
printer front, to check the paper feed function and tear off the paper.
• Close the Control Unit door.
